1.5 to 2.0 Ton Central Ducted AC (Approx. 18,000 – 24,000 BTU)
Entry-level
central system designed for compact apartments, premium small offices, or a
dedicated single zone (like a theater room) up to 600 sq. ft.
2.5 to 3.0 Ton Central Ducted AC (Approx. 30,000 – 36,000 BTU)
Whole-home
solution tailored for standard 2 to 3-bedroom single-story houses, townhomes,
and retail shops up to 1,200 sq. ft.
4.0 to 5.0 Ton Central Ducted AC (Approx. 48,000 – 60,000 BTU)
High-capacity
system engineered for large multi-story homes, expansive open-plan villas,
showrooms, and restaurants up to 2,000 sq. ft.7.5 Ton Ducted Central AC & Beyond (Approx. 90,000+ BTU)
Light
industrial and heavy commercial ducted infrastructure built for wedding halls,
corporate offices, gyms, and entire commercial floors up to 3,500+ sq. ft.
1.5 to 2.0 Ton Central Ducted AC (Approx. 18,000 – 24,000 BTU)
This
is the smallest capacity tier for a ducted configuration. It is typically
installed in premium high-end apartments where wall space is tightly preserved.
A 1.5 to 2 Ton ducted unit utilizes a compact indoor blower that fits into
shallow ceiling bulkheads or drop spaces. It can easily feed 2 to 3 small
linear grilles to cool a living room and adjacent open kitchen seamlessly
without the aesthetic distraction of wall units.
2.5 to 3.0 Ton Central Ducted AC (Approx. 30,000 –
36,000 BTU)
The
standard benchmark size for typical residential properties. A 3 Ton ducted
system has enough static pressure to force chilled air through a medium-sized
branching trunk of insulated flexible ducting. This capacity tier is highly
optimized for smart electronic zoning packages, allowing the homeowner to split
the property into separate daytime (living areas) and nighttime (bedrooms)
cooling sectors to optimize power conservation.
4.0 to 5.0 Ton Central Ducted AC (Approx. 48,000 –
60,000 BTU)
This
tier represents the upper limit of typical residential applications and the
entry point for commercial properties. A 5 Ton ducted system uses heavy-duty
blowers and an expansive outdoor condenser unit to manage high thermal stress
(such as large west-facing glass windows or high-density seating areas). They
feature advanced multi-stage or variable-speed scroll compressors that adjust
capacity dynamically to handle large shifts in daily occupancy.
7.5 Ton Ducted Central AC & Beyond (Approx.
90,000+ BTU)
Representing
true commercial HVAC application, a 7.5 Ton ducted system moves away from
typical consumer hardware. These systems require heavy structural roof or
ground pad placement for the outdoor units and utilize 3-phase electrical
power. They are engineered to move huge volumes of air continuously through
complex, rigid sheet-metal duct structures. They feature integrated outdoor
fresh-air intake integration to comply with building ventilation codes and
smoothly link with automated Building Management Systems (BMS).
