HT & LT Switchgear Panels

HT & LT Switchgear Panels are critical components of electrical power distribution networks. They provide safe switching, protection, monitoring, and control of electrical power from incoming supply sources to various loads.

HT (High Tension) Switchgear Panels are used for medium/high voltage systems, typically installed on the primary side of transformers to control and protect power distribution equipment. They include components such as circuit breakers, isolators, protection relays, CTs, PTs, and busbars.

LT (Low Tension) Switchgear Panels are used on the low-voltage side of transformers for distributing electrical power to buildings, machinery, lighting systems, and other connected loads. LT panels include MCC panels, PCC panels, distribution boards, capacitor panels, and feeder panels.

These systems are widely used in factories, commercial buildings, power plants, substations, hospitals, shopping malls, and large infrastructure projects.

Key Features

• Safe power switching and isolation
• Short-circuit and overload protection
• High-quality busbar systems
• Circuit breaker protection
• Metering and monitoring facilities
• Protection relay integration
• Modular panel construction
• Indoor and outdoor installation options
• Arc protection features (selected models)
• Compatible with SCADA and BMS systems
• Easy maintenance and expansion

Common Applications

• Industrial Plants
• Electrical Substations
• Power Generation Facilities
• Commercial Buildings
• Shopping Malls
• Hospitals
• Data Centers
• Textile & Manufacturing Factories
• Infrastructure Projects
• Utility Distribution Networks

Common HT Switchgear Panel Types

• HT VCB Panel (Vacuum Circuit Breaker Panel)
• RMU (Ring Main Unit)
• HT Metering Panel
• HT Incoming Panel
• HT Outgoing Feeder Panel
• Transformer Protection Panel
• Motor Control HT Panel

Common LT Switchgear Panel Types

• PCC (Power Control Center) Panel
• MCC (Motor Control Center) Panel
• LT Distribution Panel
• AMF Panel
• APFC Panel (Automatic Power Factor Correction)
• Synchronizing Panel
• Feeder Pillar Panel
• Lighting Distribution Panel

Typical Specifications

HT Switchgear

• Voltage Range: 3.3 kV – 33 kV (typical)
• Frequency: 50/60 Hz
• Insulation Level: IEC 62271 standard
• Protection: VCB, Relay, CT, PT

LT Switchgear

• Voltage Range: Up to 1000V AC
• Current Rating: 100A – 6300A+
• Short Circuit Rating: Up to 100 kA
• Standards: IEC 61439
